Tripp-Lite 9PXPPDM1G2 | 9PX G2 PowerPass Distribution Module for 3k...
Description
Description
The 9PXPPDM1G2 converts your UPS system’s 208V high-voltage input to 120V low-voltage output. It features one L6-30R, one L14-30R and six NEMA 5-20R outlets for connecting equipment. Resettable 30A circuit breakers protect against overload conditions. The 9PXPPDM1G2 works with Eaton’s 9PX5KG2, 9PX6KG2, 9PX6K-L and 9PX3K3UG2 UPS systems. Its front-panel mainenance bypass switch lets you service or replace the UPS system without powering down any equipment and risking costly downtime. All connected equipment remains energized, even while the UPS system is not present.
Tripp-Lite - 9PXPPDM1G2 - Features
- Converts high-voltage AC output into low voltage for powering low-voltage equipment
- Provides extra protection against power spikes and surges that can damage equipment
- Resettable circuit breakers protect connected equipment from hazardous overloads
- Maintenance bypass allows UPS service or replacement without powering down load
Specifications
Specifications
Tripp-Lite - 9PXPPDM1G2 - Specifications
| Type | Uninterruptible Power Supply |
|---|---|
| UNSPSC Code | 39121011 |
| UPC Code | 786689876036 |
| Input Phase | Single-Phase |
| Input Plug Type | NEMA L6-30P |
| Output Receptacles | (6) 5-20R; (1) L14-30R; (1) L6-30R |
| Primary Form Factor | Rackmount; Tower |
| Rack Height | 3U |
| External Battery Pack Form Factor | Rack/Tower |
| Unit Dimensions (hwd / in.) | 5.100 x 17.300 x 25.040 |
| Operating Temperature Range | 32° to 104°F (0° to 40°C) |
| Relative Humidity | 0-95% non-condensing |
