RFS Technologies Inc 43F-LCF12-D01 | 4.3-10 Female Connector, 50 Ohm, 6 GHz
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
RFS Technologies Inc 43F-LCF12-D01 | 4.3-10 Female Connector, 50 Oh...
Description
Description
OMNI FIT high-performance connectors are designed for use with both CELLFLEX (copper) and CELLFLEX Lite (aluminum) cables. They are designed specifically to provide the highest quality connector-cable interface while simplifying and speeding up connector attachment. All RFS connectors are fully tested for mechanical and electrical compliance to industry specifications. The 4.3-10 connector is an innovative, space-saving RF connection meeting all requirements even under the most severe environmental conditions and not relying on coupling nut torque. Sealing against outer conductor and jacket by means of the polymer claw and 360 deg. compression fit. Multifunctional, self-lubricating HighTech polymer assembly locks on cable corrugation, avoids electrochemical potential differences and compression-fits to the jacket.
Specifications
Specifications
RFS Technologies Inc - 43F-LCF12-D01 - Product Categories
- Networking and Wireless
- Wireless
- Wireless Cabling and Connectors
- Wireless Connectors
RFS Technologies Inc - 43F-LCF12-D01 - Specifications
| Manufacturer Part Number | 43F-LCF12-D01 |
|---|---|
| Manufacturer | RFS Technologies Inc |
| Connection Size | 4.3-10 |
| Connection Type | Female |
| Dimensions | LxDia: 2.34 x 1.18 in. |
| Finish | NiTin Outer, Silver Inner |
| For Cable Type | 1/2 in. Foam Dielectric Coaxial Cable |
| Frequency Rating | 6GHz |
| Impedance | 50 ? |
| Product Type | Straight Premium Connector |
| SCREEN/SHIELD TYPE | UNSHIELDED |
