Corning 012KSF-T4130D20 | Freedm Lst(Tm) Single-Tube, Gel-Free Cable, Riser, 12 Fiber, 62.5 µm Multimode (Om1)
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 012KSF-T4130D20 | Freedm Lst(Tm) Single-Tube, Gel-Free Cabl...
Description
Description
Corning FREEDM LST gel-free cables are flame-retardant, indoor/outdoor, riser-rated cables designed for interbuilding and intrabuilding backbones in aerial, duct and riser applications. With a riser rating, there is no need for a transition splice when entering the building. Available in a compact design, these cables are protected against water penetration by innovative waterblocking tapes and yarns that swell to absorb water. Waterblocking without the use of messy gels provides more efficient and craft-friendly cable preparation, allows easier cable access and simplifies the use of buffer tube fan-out kits. The buffer tubes and fibers in each tube are color coded for quick, easy identification.
Note: This cable is available in 12 different jacket colors - blue, orange, green, brown, slate, white, red, black, yellow, violet, rose and aqua. The colored jacket allows for easy visual identification of the cables while still providing all of the required environmental protection of an indoor/out door cable jacket. Black is the standard jacket color using the part numbers shown here. Contact Customer Care at 1-800-743-2675 to order other color options.
Corning - 012KSF-T4130D20 - Features
- Riser rating
- No transition splices when entering buildings Gel-free waterblocking technology
- Craft-friendly cable preparation Color-coded fibers
- Quick and easy identification All-dielectric construction
- Requires no grounding or bonding UV-resistant, ame-retardant jacket
- Rugged, durable and easy to strip Common installations
- Outdoor aerial and duct; indoor vertical riser and general purpose horizontal according to NEC Article 770
- Aerial, Direct Buried, Duct, General Purpose Horizontal, Vertical Riser
Specifications
Specifications
Corning - 012KSF-T4130D20 - Specification Description
- Cable Type: Loose Tube
- Environment: Indoor/Outdoor
- Fiber Category: 62.5 µm MM (OM1)
- Flame Rating: Riser (OFNR)
- Product Type: Dielectric
- Fiber Coloring: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet, Rose, Aqua
- Fiber Count (cable): 12
- Fibers per Tube: 12
- Number of Active Tubes: 1
- Number of Ripcords: 1
- Number of Tube Positions: 1
- Outer Jacket Color: Black
- Outer Jacket Material: Flame-Retardant, UV-Resistant
- Tensile Strength Elements and/or Armoring - Layer 1: Dielectric strength members
- Tensile Strength Elements and/or Armoring - Layer 2: Water-swellable dielectric strength members
- Max. Tensile Strengths, Long-Term (Metric): 400 N
- Max. Tensile Strengths, Long-Term (US): 90 lbf
- Max. Tensile Strengths, Short-Term (Metric): 1350 N
- Max. Tensile Strengths, Short-Term (US): 300 lbf
- Min. Bend Radius Installation (Metric): 111 mm
- Min. Bend Radius Installation (US): 4.4 in
- Min. Bend Radius Operation (Metric): 37 mm
- Min. Bend Radius Operation (US): 1.5 in
- Nominal Outer Diameter (Metric-mm): 7.4 mm
- Nominal Outer Diameter (US): 0.29 in
- Weight (cable) (Metric): 56 kg/km
- Weight (cable) (US): 38 lb/1000 ft
- Temperature - Installation (Metric): -10 C to 60 C
- Temperature - Installation (US): 14 F to 140 F
- Temperature - Operation (Metric): -40 C to 70 C
- Temperature - Operation (US): -40 F to 158 F
- Temperature - Storage (Metric): -40 C to 70 C
- Temperature - Storage (US): -40 F to 158 F
- Tech Info
- Approval and Listings: National Electrical Code (NEC) OFNR, CSA OFN FT-4; Common Installations: Outdoor lashed aerial and duct; indoor vertical riser and general purpose horizontal according to National Electrical Code (NEC) Article 770; Design and Test Criteria: ANSI/ICEA S-104-696; Free of hazardous substances according to RoHS 2002/95/EG
Corning - 012KSF-T4130D20 - Specifications
| All-Dielectric | Yes |
|---|---|
| Armored | No |
| Cable Type | Loose Tube |
| Fiber Count | 12 |
| Fiber Type | Om1 62.5 Micron Multimode |
| Fire Rating | Riser |
| Rodent Protected | No |
| UNSPSC Code | 26121607 |
