Brand: Corning
|
SKU:
10311296
Corning U9U902QD120007M | Edge Lockable Uniboot Jumpers LC Duplex to LC Duplex, 2 F, 50 µm multimode (OM4), DFX 250 Riser, 7 m, 2.0 mm
Regular price
$76.51
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning U9U902QD120007M | Edge Lockable Uniboot Jumpers LC Duplex ...
Regular price
$76.51
Unit price
Description
Description
Corning U9U902QD120007M | Edge Lockable Uniboot Jumpers LC Duplex to LC Duplex, 2 F, 50 µm multimode (OM4), DFX 250 Riser, 7 m, 2.0 mm
Specifications
Specifications
Corning - U9U902QD120007M - Product Categories
- Fiber Optic Cable Assemblies
- Indoor Cable Assemblies
- Two Fiber Indoor Cable Assemblies
Corning - U9U902QD120007M - Specifications
| Brand Name | Corning |
|---|---|
| Manufacturer Part Number | U9U902QD120007M |
| Item Description | Edge Lockable Uniboot Jumpers LC Duplex to LC Duplex, 2 F, 50 µm multimode (OM4), DFX 250 Riser, 7 m, 2.0 mm |
| General Specifications | - |
| Product Number | U9U902QD120007M |
| Flame Rating | Riser (OFNR) |
| Fiber Category | 50 µm MM (OM4) |
| Application | Data Center, General Building Applications, Vertical Riser |
| Assembly Insertion Loss | 0.5dB |
| Connector Assembly Type | LC Duplex Uniboot to LC Duplex Uniboot |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Design | - |
| Fiber Count | 2 |
| Outer Jacket Material | Riser (OFNR) |
| Outer Jacket Color | Aqua |
| Fiber Type | Multimode |
| Fibers per Port | 2 |
| Housing Color | Aqua |
| Mechanical Specifications | - |
| Min. Bend Radius Installation | 10mm (0.39in) |
| Cable Length | 7m (22.96ft) |
| Optical Characteristics | - |
| Fiber Code | T |
| Fiber Type | Multimode |
| Performance Option Code | 90 |
| Fiber Core Diameter | 50µm |
| Minimum Effective Modal Bandwidth (EMB) | 4700 MHz*km / - |
| Maximum Attenuation | 3.0 dB/km / 1.0 dB/km |
| Min. Overfilled Launch (OFL) Bandwidth | 3500 MHz*km / 500 MHz*km |
| Serial 1 Gigabit Ethernet | 1100 MHz*km / 600 MHz*km |
| Serial 10 Gigabit Ethernet | 550 MHz*km / - |
| Wavelengths | 850 nm / 1300 nm |
| Fiber Category | OM4 |
| Specifications - Connector A | - |
| Polish | UPC |
| Insertion Loss, Max. | 0.5dB |
| Boot Color | Aqua |
| Connector Type | LC Uniboot |
| Ferrule Material | Ceramic |
| Housing Color | Aqua |
| Housing Material | Composite |
| Specifications - Connector B | - |
| Polish | UPC |
| Insertion Loss, Max. | 0.5dB |
| Boot Color | Aqua |
| Connector Type | LC Uniboot |
| Ferrule Material | Ceramic |
| Housing Color | Aqua |
| Dimensions | - |
| Outer Diameter | 2mm (0.08in) |
