Panduit IMSP16T35-QR6L | StrongHold™ Fully Coated Metal Strapping Coil
Description
Description
The Pan-Steel I-series metal Strapping system is available in 316L stainless steel to deliver high performance, strength, and reliability, ideal for the sign and signal, oil and gas, and Industrial markets. Designed to work together in extreme conditions, the I-series metal strapping, buckles, and installation tool provide secure connections while offering lower installed costs. This system is part of the complete range of harsh environment solutions.
Panduit Pan-Steel Metal Strapping System, Heavy Duty, Series: I Series, 82.02 in Length, 0.63 in Width, 0.014 in Thickness, 26 mm Bundle Dia, Fold Over, 700 lb Tensile, -112 to 1000 deg F, 316 Stainless Steel, Natural
Transform your projects with our stainless steel strapping coils. Designed for reliability and efficiency, they ensure strong connections and boost productivity in any environment
StrongHold IMSP16T35-QR6L Coated Metal Strapping Coils offer contractors an economical option for mechanical fastening. They provide secure connections while offering a lower installed cost and enhanced productivity. Made of 316L stainless steel and ar e coated in epoxy polyester. They are 82 x 0.6 (25m x 16mm) in size and come individually packaged. Pair with StrongHold buckles for the complete solution.
Panduit - IMSP16T35-QR6L - Features
- Color specific keys with positive and negative keying features
- Factory terminated and 100% tested for insertion loss and return loss
- Certified 10 GbE performance
- Test data supplied with each patch cord and pigtail
- Universal reference cords
- Applications: Perfect for some of the most challenging industries, including sign and signal, oil and gas and industrial
- Smooth surface and round edges, assures worker safety and bundle protection from abrasion during and after installation
- Easy to dispense coil packaging
- Compatible with industry standard tools
Specifications
Specifications
Panduit - IMSP16T35-QR6L - Specifications
| Category | Strapping And Accessories |
|---|---|
| Product Type | Straps |
| Size | None |
| UNSPSC Code | 46182300 |
| Technical Information | UL Listed (File # E56854), RoHS Compliant |
| Product Type | Strapping |
| Application | Perfect for some of the most challenging industries, including sign and signal, oil and gas and industrial |
| Color | Black |
| Environment | Indoor and Outdoor |
| Finish/Coating | Fully Coated |
| For Use With | BT75SDT |
| Material | Stainless Steel Type 316 |
| Minimum Loop Tensile Strength (N) | 3110 |
| Minimum Loop Tensile Strength (lb) | 700 |
| Overall Length (In.) | 984.24 |
| Overall Length (mm) | 25000 |
| Overall Width (In.) | 0.63 |
| Overall Width (mm) | 16 |
| Resistance Properties | Flame-Resistant |
| Standards Met | UL Listed (File # E56854),RoHS Compliant |
| Sub Brand | StrongHold™ |
| Strap Breaking Strength (N) | 3110 |
| Strap Breaking Strength (lb) | 700 |
| Minimum Bundle Width (In.) | 1.02 |
| Minimum Bundle Width (mm) | 26 |
| Overall Thickness (In.) | 0.014 |
| UPC | 61305601529 |
Panduit - IMSP16T35-QR6L - Package Information
| UPC | 61305601529 |
|---|---|
| Standard Packaging Quantity | 1 |
| Standard Packaging Volume (cf) | 0.0669 |
| Standard Ctn. Quantity | 10 |
| Standard Ctn. Volume (cf) | 0.6688 |
