6MCAP-1003S-120-250 - 10-3 STR CU THHN AL
Description
Description
Branch-circuit wiring in commercial, industrial, institutional, and multi-residential buildings. Power, lighting, control, and signal circuits in concealed or exposed installations. Fished or embedded in plaster. Environmental air-handling spaces per NEC 300.22(C). Places of Assembly per NEC 518.4 and theaters per NEC 520.5. Installation in cable tray and approved raceways. Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) & 645.5(D)(2).
Approved Manufacturers - 6MCAP-1003S-120-250 - Features
- All Purpose Cable May Be Used Wherever Standard AC or MC Cable is Permitted
- Lightweight Aluminum Interlocked Armor
- 600 Volt
- Copper THHN Insulated Circuit Conductors
- Full-sized Aluminum Equipment Grounding/ Bonding Conductor
- Sizes 14, 12, and 10 AWG
- UL L
Specifications
Specifications
Approved Manufacturers - 6MCAP-1003S-120-250 - Product Categories
- Shop by Manufacturer/Approved Manufacturers
- Wire and Cable
- Electrical Wire and Cable
- Control and Power Cable
Approved Manufacturers - 6MCAP-1003S-120-250 - Specifications
| Armor | Yes |
|---|---|
| Composite | No |
| Conductor Count | 3 Conductor |
| Conductor Material | Bare Copper |
| Conductor Size | 10 AWG |
| Conductor Type | Stranded |
| Earth/Ground Wires | Yes |
| Insulation Material | PVC/Nyl-Polyvinyl Chloride/Nylon |
| Jacket Material | Unjacketed/Non-Sheathed |
| Number of Ground Wires | 1 Wire |
| Product Type | Metal Clad Building Wire |
| Screen/Shield | Unshielded |
| Voltage Range | 600V |
| UNSPSC Code | 26121600 |
