Brand: Approved Manufacturers
|
SKU:
7V-0803-3G
7V-0803-3G - Power Cable, 8 AWG, 3#14 AWG
Regular price
$4,363.18
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
7V-0803-3G - Power Cable, 8 AWG, 3#14 AWG
Regular price
$4,363.18
Unit price
Brand: Approved Manufacturers
|
SKU:
7V-0803-3G
Regular price
$4,363.18
Unit price
Shipping calculated at checkout.
Description
Description
Power Cable, 8 AWG, 3#14 AWG Ground Wire, 3 Conductor, 2000 V, 55 Amps Per Conductor, 7 Strands, XLP Insulation, Impervious Continuous Corrugated Aluminum Armor, PVC, Black
AC drive cables Impervious continuous corrugated aluminum armor XLP insulation.
Approved Manufacturers - 7V-0803-3G - Features
- Conductor: Bare Copper
- Insulation: Cross-linked Polyethylene (XLP)
- Temperature: 90C
- Voltage: 2 KV
Specifications
Specifications
Approved Manufacturers - 7V-0803-3G - Product Categories
- Shop by Manufacturer/Approved Manufacturers
- Wire and Cable
- Electrical Wire and Cable
- Control and Power Cable
Approved Manufacturers - 7V-0803-3G - Applications
- Primary power for all types of AC motor drives, especially between PWM inverters and AC motors. Cable may be used in all types of industrial and processing facilities. This cable also can be used for many other power applications in most environments.
- AC drive cables
- Impervious continuous corrugated aluminum armor
- XLP insulation
Approved Manufacturers - 7V-0803-3G - Specifications
| Armor | Yes |
|---|---|
| Composite | No |
| Conductor Count | 3 Conductor |
| Conductor Material | Bare Copper |
| Conductor Size | 8 AWG |
| Conductor Type | Stranded |
| Earth/Ground Wires | Yes |
| Insulation Material | XLPE-Cross-Linked Polyethylene |
| Jacket Material | PVC-Polyvinyl Chloride |
| Number of Ground Wires | 3 Wire |
| Product Type | Ccw |
| Screen/Shield | Unshielded |
| Voltage Range | 2KV |
| UNSPSC Code | 26121600 |
