Advantech SFP-FSS-40KTX | IE-SFP/155-ED, SSFX-SM1310/Plus-SC (1310Xmt/1550Rcv) Transceiver
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Advantech SFP-FSS-40KTX | IE-SFP/155-ED, SSFX-SM1310/Plus-SC (1310X...
Description
Description
IE-SFPs, SFP+’s and XFPs are compact transceivers which function as modular connectors. Available for copper (RJ45) and all common fiber modes, wavelengths and data rates, they allow network operators to connect different interface types into the same network equipment, via an SFP/SFP+/XFP port. The cost of cable upgrades is greatly reduced - preserving the investment in costly networking equipment, for the price of a relatively inexpensive SFP, SFP+ or XFP. More and more network equipment is being designed with these ports to take advantage of their flexibility, and to take the uncertainty and guesswork out of expensive equipment purchases.
Advantech - SFP-FSS-40KTX - Features
- Fixed fiber ports don’t offer users much flexibility. Removable SFP modules make it easy to connect either Multimode or Single-mode fiber on the fly.
- 155 Mbps: Compliant with ITU-T G.957, G.958 and IEEE 802.3u
- 1.25 Gbps: Compliant with IEEE802.3z
- 2.4 Gbps: Compliant with ITU-T G.957, G.958
- Multi-source package with Duplex LC connector or Single-Strand fiber SC connector
- Eye Safety designed to meet Laser Class 1 compliance with IEC 60825-1
- Single 3.3V power source
- Hot-swappable
- Monitoring interface compliance with SFF-8472
- Complies with Telecordia (Bellcore) GR-468-CORE, TA-NWT-000983
- Provides digital diagnostics monitoring (DDM) functionality
- Wide specifications and fiber types available
- Industrial standard small form-factor pluggable (SFP) package
- Comes with metal enclosure for EMI
- The Class 1 laser product complies with EN 60825-1
- Supports plug-n-play operation
Specifications
Specifications
Advantech - SFP-FSS-40KTX - Product Categories
- Industrial
- Industrial Communication and Control
- Industrial Communication and Control
Advantech - SFP-FSS-40KTX - Specifications
| Brand Name | Advantech |
|---|---|
| Manufacturer Part Number | SFP-FSS-40KTX |
| Type | Media Converter |
| UNSPSC Code | 43201553 |
| Speed | 100~155 Mbps |
| Optical Mode | Bi-Directional |
| Optical Wavelength | 1310T / 1550R |
| Optical Connector | Simplex SC |
| Max. Distance | 40 km |
| Operating Temperature | -40 to +85°C (-40 to +185°F) |
