Ag Neovo Technology SC32AH | Ag Neovo Sc-32Ah 32" 1080P Ahd Le...
Description
Description
Monitor from AG Neovo is a surveillance display equipped with analog HD-over-Coax video capabilities that supports zero-latency transmission of 1080p video over a coaxial cable. It features multiple connectivity options, including S-Video, VGA, and HDMI inputs, along with AHD 2.0, TVI 2.0, and CVBS (NTSC/PAL) loop through input/output via BNC. It also features stereo audio 3.5mm input/output jacks and two 2W built-in speakers. The monitor uses anti-burn-in technology, which is suitable for surveillance displays that operate 24/7. It also features built-in image enhancement functions like 3D comb filter, de-interlace, and noise reduction.
Ag Neovo Technology - SC32AH - Features
- LED-backlit TFT LCD display with 1920 x 1080 resolution
- Anti-burn-in technology
- Built-in image enhancer offers 3D comb filter, de-interlace, and noise reduction
- MVA panel offers wide viewing angles up to 178°
- S-Video, VGA, and HDMI inputs along with stereo audio input/output
- Analog interface AHD 2.0, TVI 2.0, and CVBS (PAL/NTSC) loop through input/output
- Quick signal-switching time
- Auto detects a video signal (AHD, TVI, CVBS)
- Selectable signal source
- Rigorous screening of the components for 24/7 applications
- Two 2W built-in speakers
- VESA standard wall mount
- Key lock function
- Auto-adjustment for optimal setting
- Tilt range from 4 to 19°
- Kensington security socket
Specifications
Specifications
Ag Neovo Technology - SC32AH - Specifications
| Brand Name | Ag Neovo Technology |
|---|---|
| Manufacturer Part Number | SC32AH |
| Item Description | Ag Neovo Sc-32Ah 32" 1080P Ahd Led-Backlit Tft Lcd Monitor |
| Application | Surveillance |
| LCD Size | 31.5" / 80 cm |
| Video System | NTSC and PAL |
| Panel Type | LED-backlit TFT LCD |
| Resolution | 1920 x 1080 |
| Horizontal Resolution (TV Lines) | 600 TVL (NTSC/PAL) |
| Pixel Pitch | 0.3637 mm |
| Response Time | 5 ms |
| Viewing Angle (H/V) | 178/178° |
| Contrast Ratio | 125.000694444444 |
| Brightness | 300 cd/m2 |
| Display Colors | 16.7M |
| Analog HD: | 720p/25, 720p/30, 720p/50, 720p/60, 1080p/25, 1080p/30 |
| Digital HD: | 720/60p, 720/59.94p, 720/50p, 1080/60i, 1080/59.394i, 1080/50i, 1080/60p, 1080/59.94p, 1080/50p |
| Scanning Frequency | Horizontal: 31 to 83 kHz, Vertical: 50 to 75 Hz |
| Picture Control | 3D comb filter, de-interlace, and noise reduction |
| Remote Control | Included |
| Input: | 1 x VGA (15-pin D-Sub), 1 x AHD 2.0/TVI 2.0/CVBS (BNC), 1 x S-Video (4-pin mini DIN), 1 x HDMI, 1 x stereo audio jack (3.5 mm) |
| Output: | 1 x AHD 2.0/TVI/CVBS (BNC), 1 x stereo audio jack (3.5 mm), 2 x 2 W speakers |
| Plug and Play | EDID |
| Power Requirements | Internal Power Supply: 100 to 240 VAC, 50 to 60 Hz |
| Power Consumption | <59 W (on) ,<0.5 W (standby), <0.5 W (off) |
| VESA Mounting | 200 x 100 mm |
| Tilt Range | 4 to 19° |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 10 to 85% (non-condensing) |
| Storage Temperature | 14 to 122°F / -10 to 50°C |
| Storage Humidity | 10 to 95% (non-condensing) |
| Certifications & Approvals | CE, FCC, GOST-R, WEEE, RoHS |
| Dimensions | 29.3 x 20.96 x 7.8" / 74.4 x 53.3 x 19.9 cm |
| Weight | 17.6 lb / 8 kg |
