Brand: Aiphone Systems
|
SKU:
319707
Aiphone AX-8MV Audio/Video Master With Buttons For Up To 8 Masters And 8 Doors
Regular price
$1,161.44
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Aiphone AX-8MV Audio/Video Master With Buttons For Up To 8 Masters ...
Regular price
$1,161.44
Unit price
Brand: Aiphone Systems
|
SKU:
319707
Regular price
$1,161.44
Unit price
Shipping calculated at checkout.
Description
Description
The AX-8MV Master Station is the centerpiece of the AX Integrated Audio & Video Security system.Each AX-8MV master station can initiate and answer calls from up to 7 additional master stations and up to 8 door or sub stations. The master can be expanded with AX-16SW add-on selectors for a maximum capacity of 120 door / sub stations. Its streamline design is mountable on a wall or desk.
Key Features
- Hands-free or push-to-talk communication
- Composite video output
- All Call or Group Call to master stations
- Scan monitoring
Specifications
Specifications
Specifications
| Name | Aiphone AX-8MV Video Door Phone, Aiphone Co., Ltd, Aiphone |
|---|---|
| Manufacturer | Aiphone Co., Ltd |
| Manufacturer Part Number | AX-8MV |
| Product Model | AX-8MV |
| Product Series | AX |
| Product Type | Video Door Phone |
| Screen Size | 3.5" |
| Input Voltage | 24 V DC |
| Depth | 1.9" |
| Weight (Approximate) | 1.21 lb |
| Height | 6.9" |
| Width | 7.6" |
| Additional Information | Call Tone: Tremolo ring tone & blinking LED, Communication: Open voice hands-free (VOX or Push-to-Talk), Scanning Lines: 525 lines, Video Output: NTSC Standard 1Vpp (0.7-1.4Vpp), Headset Jack: 3.5mm mic and speaker jacks, Calling Capacity: Up to 7 additional master stations Up to 120 door / sub stations, Mounting: Desk with flip-up stands, or wall mount with provided metal bracket, Wall mount box:2-gang electrical box or ring, Wiring: CAT-5e homerun to CEU, Wiring Connection:RJ45 jack, Housing: ABS Resin, Color: Black |
| Package Contents | AX-8MV Video Door PhoneMetal Bracket |
