Alpha Wire 1559 GR005 | Hook Up Wire, MIL-W-76B/Type MW, 14 AWG - 41/30 Stranded Conductor, 1000V - Green - 100ft
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 1559 GR005 | Hook Up Wire, MIL-W-76B/Type MW, 14 AWG - 4...
Description
Description
The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment.Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.
Specifications
Specifications
Alpha Wire - 1559 GR005 - Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 14 (41/30) AWG Tinned Copper |
| Insulation | 0.016" Wall, Nom. PVC |
| Color | Green |
| length | 100 FT. |
| Temperature Range | -40 to 80°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 32 Lbs, Maximum |
| Voltage Rating | 1000 VRMS |
| Inductance | 0.04 ?H/ft, Nominal |
| Conductor DCR | 2.8 ?/1000ft @20°C, Nominal |
