Brand: Alpha Wire
|
SKU:
A1651-2
Alpha Wire 1651 RD001 | 12 AWG Hook-Up Wire 65/30 Red 600V 1000.0' (304.8m)
Regular price
$6.76
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 1651 RD001 | 12 AWG Hook-Up Wire 65/30 Red 600V 1000.0&#...
Regular price
$6.76
Unit price
Description
Description
12 AWG Hook-Up Wire 65/30 Red 600V 1000.0' (304.8m)
Specifications
Specifications
Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 12 (65/30) AWG TC |
| Insulation | 0.045" Wall, Nom. PVC |
| Color(s) | WHITE, BLACK, RED |
| EU Directive 2011/65/EU(RoHS2): | All materials used in the manufacture of this part are in compliance with European Directive 2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and electronic equipment. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| California Proposition 65: | The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 80°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 51 Lbs, Maximum |
| Voltage Rating | 600 VRMS |
| Conductor DCR | 1.75 ?/1000ft @20°C, Nominal |
