Brand: Alpha Wire
|
SKU:
A25194-9
Alpha Wire 25194 WH199 | 4 Conductor Multi-Conductor Cable White 22 AWG Foil 1000' (304.8M)
Regular price
$7.16
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 25194 WH199 | 4 Conductor Multi-Conductor Cable White 22...
Regular price
$7.16
Unit price
Description
Description
Alpha Wire 25194 WH199 | 4 Conductor Multi-Conductor Cable White 22 AWG Foil 1000' (304.8M)
Specifications
Specifications
Specifications
| Categories | Cables, Wires |
|---|---|
| Manufacturer | Alpha Wire |
| Series | Xtra-Guard 2 |
| Packaging | Spool |
| Part Status | Active |
| Cable Type | Multi-Conductor |
| Number of Conductors | 4 |
| Wire Gauge | 7/30 |
| Conductor Material | Copper, Tinned |
| Jacket (Insulation) Material | Polyurethane (PU) |
| Jacket (Insulation) Diameter | 0.193" (4.90mm) |
| Shield Type | Foil |
| Length | 1000.0' (304.8m) |
| Jacket Color | White |
| Ratings | ISO 10993, UL Style 20668 |
| Features | Biological Compatibility, Drain Wire, Rip Cord |
| Voltage | 300V |
| Operating Temperature | -30°C ~ 90°C |
| Jacket (Insulation) Thickness | 0.0320" (0.813mm) |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Shield Material | Aluminum |
| Shield Coverage | 100% |
| Base Part Number | 25194 |
Environmental & Export Classifications
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Additional Resources
| Standard Package | 1,000 |
|---|---|
| Other Names | 25194 WH199-ND, 25194WH199 |
