Alpha Wire 2936 RD001 | ThermoThin Hook-up Wire, 36 AWG, Solid, 600V, Red, 1000ft
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 2936 RD001 | ThermoThin Hook-up Wire, 36 AWG, Solid, 600...
Description
Description
Alpha Wire’s new ThermoThin hook-up wire line offers reliable performance in applications that are exposed to a broad temperature range. Designed to withstand temperatures from -150C to +300C, ThermoThin is ideal for military, energy generation, oil and gas, and other mission-critical applications.
ThermoThin is available in conductor sizes from 36 AWG to 16 AWG, offering another hook-up wire solution to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.
Alpha Wire - 2936 RD001 - Features
- Exceptionally small and lightweight
- 36 AWG to 16 AWG conductor range
- Nickel-plated copper conductors
- ECA fluoropolymer insulation
- -150C to +300C temperature range
- 600 V performance
- Excellent UV, chemical, and water resistance
- UL AWM 11540 (30 AW larger)
- 1000 ft continuous length available compared to
- 3 pieces per 1000 ft put up for PTFE
- Passes UL horizontal flame (30 AWG and larger)
Specifications
Specifications
Alpha Wire - 2936 RD001 - Product Categories
- Wire & Cable
- Electronic Wire and Cable
- UL / CSA / Mil-spec Leadwire
Alpha Wire - 2936 RD001 - Specifications
| Brand Name | Alpha Wire |
|---|---|
| Manufacturer Part Number | 2936 RD001 |
| Item Description | ThermoThin Hook-up Wire, 36AWG, Solid, 600V, Red, 1000 FT |
| Conductor Material | Nickel Plated Copper |
| Conductor Size | 36 Awg (American Wire Gauge) |
| Insulation Color | Red |
| Conductor Stranding | 1 Strand In Each Conductor (Solid) |
| Product Type | Ul Style 10000 Series |
| Rohs Compliant | Yes |
| Shielded | Not Shielded |
| UNSPSC Code | 26121539 |
