Brand: Alpha Wire | SKU: A3057-97

Alpha Wire 3057 WH001 | Hook Up Wire, 16AWG, 1000 Ft, White

Regular price $1.46
  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Description

Alpha Wire 3057 WH001 | Hook Up Wire, 16AWG, 1000 Ft, White

The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment.Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.

Specifications

Alpha Wire - 3057 WH001 - Specifications

Component 11 X 1 HOOKUP
Conductor18 (16/30) AWG Tinned Copper
Insulation0.006" Wall, Nom. PTFE
ColorWhite
Temperature Range-40 to 105°C
Bend Radius10X Cable Diameter
Pull Tension20.4 Lbs, Maximum
Voltage Rating300 VRMS
Inductance0.04 ?H/ft, Nominal
Conductor DCR4.4 ?/1000ft @20°C, Nominal
