Alpha Wire 3079 WHT/RED | Hook Up Wire, Ul1015 14 41 Stranded TNC PVC White/Red Spiral Stripe
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 3079 WHT/RED | Hook Up Wire, Ul1015 14 41 Stranded TNC P...
Description
Description
The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment.Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.
Specifications
Specifications
Alpha Wire - 3079 WHT/RED - Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 14 AWG Tinned Copper |
| Insulation | 0.032" Wall, Nom. PVC |
| Color | White, Red |
| Temperature Range | -40 to 105°C |
| Bend Radius | 5X Cable Diameter |
| Pull Tension | 32 Lbs, Maximum |
| Voltage Rating | 600 VRMS |
| Inductance | 0.05 ?H/ft, Nominal |
| Conductor DCR | 2.8 ?/1000ft @20°C, Nominal |
