Brand: Alpha Wire
|
SKU:
A421626-6
Alpha Wire 421626 BL001 | 16 AWG AWM 1061 Hook-Up Wire, 80°C, 300V, VW-1/FT1, CSA/CE, RoHS, Blue
Regular price
$1.43
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 421626 BL001 | 16 AWG AWM 1061 Hook-Up Wire, 80°C, 300V,...
Regular price
$1.43
Unit price
Description
Description
Alpha Wire 421626 BL001 | 16 AWG AWM 1061 Hook-Up Wire, 80°C, 300V, VW-1/FT1, CSA/CE, RoHS, Blue
The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment.
Specifications
Specifications
Alpha Wire - 421626 BL001 - Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 16 (26/30) AWG Tinned Copper |
| Temperature Range | -10 to 80°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 20.4 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Inductance | 0.03 ?H/ft, Nominal |
| Conductor DCR | 4.4 ?/1000ft @20°C, Nominal |
