Alpha Wire 5110/25C BK199 | Bulk FT Each
Regular price
$41.77
Unit price
Brand: Alpha Wire
|
SKU:
A5110/25C-BLK
Regular price
$41.77
Unit price
Description
Description
Alpha Wire 5110/25C BK199 | 5110/25C BLACK 1000 = 1000 FT
Specifications
Specifications
Specifications
| Categories | Cables, Wires |
|---|---|
| Manufacturer | Alpha Wire |
| Series | Xtra-Guard 1 |
| Packaging | Spool |
| Part Status | Active |
| Cable Type | Multi-Conductor |
| Number of Conductors | 25 |
| Wire Gauge | 7/30 |
| Conductor Material | Copper, Tinned |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Diameter | 0.396" (10.06mm) |
| Shield Type | Foil, Braid |
| Length | 1000.0' (304.8m) |
| Jacket Color | Black |
| Ratings | ISO 10993, UL Style 2464 |
| Features | Biological Compatibility, Drain Wire, Rip Cord |
| Voltage | 300V |
| Operating Temperature | -35°C ~ 105°C |
| Usage | Communication, Control |
| Jacket (Insulation) Thickness | 0.0320" (0.813mm) |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Shield Material | Suprashield; Copper, Tinned |
| Shield Coverage | 100%, 70% |
| Base Part Number | 5110/25C |
Environmental & Export Classifications
| RoHS Status | ROHS3 Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
Additional Resources
| Standard Package | 1,000 |
|---|---|
| Other Names | 5110/25C BK199-ND, 5110/25CBK199 |
