Brand: Alpha Wire
|
SKU:
A5422-100
Alpha Wire 5422 SL005 | Multicore Cable, 2 Cores, 0.75 mm, Unscreened, 100 Feet, Grey PVC Sheath, 18 AWG
Regular price
$8.61
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 5422 SL005 | Multicore Cable, 2 Cores, 0.75 mm, Unscreen...
Regular price
$8.61
Unit price
Description
Description
Alpha Wire 5422 SL005 | Multicore Cable, 2 Cores, 0.75 mm, Unscreened, 100 Feet, Grey PVC Sheath, 18 AWG
Alpha Wire - 5422 SL005 - Features
- High-performance cable for general-purpose applications
- Features a unique, premium-grade PVC insulation and jacket for Easier routing of cable in small spaces
- Provides resistance to oils per UL Oil Res I (60C OIL RES) and Class 43
- Designed for use in ambient temperatures up to 105 ° C
Specifications
Specifications
Alpha Wire - 5422 SL005 - Specifications
| Number of Cores | 2 |
|---|---|
| Cross Sectional Area | 0.75 mm² |
| American Wire Gauge | 18 AWG |
| Sheath Material | Polyvinyl Chloride PVC |
| Sheath Colour | Grey |
| Screened/Unscreened | Unscreened |
| Length | 100ft |
| Component 1 | 2 X 1 COND |
| Conductor | 18 (16/30) AWG Tinned Copper |
| Insulation | 0.032" Wall, Nom. PVC |
| (Color Code | Alpha Wire Color Code E |
| Temperature Range | -30 to 105°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 25 Lbs, Maximum |
| Sunlight Resistance | Yes |
| Voltage Rating | 600 VRMS |
| Capacitance | 23.3 pF/ft @1 kHz, Nominal Conductor to Conductor |
| Characteristic Impedance | 93 ? |
| Inductance | 0.22 ?H/ft, Nominal |
| Conductor DCR | 7 ?/1000ft @20°C, Nominal |
