Brand: Alpha Wire
|
SKU:
A5875-92
Alpha Wire 5875 WHT/RED | Hook-up Wire, 22 AWG, 1 Conductor, 19 Stranded, White/Red Spiral Stripe 1000V
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 5875 WHT/RED | Hook-up Wire, 22 AWG, 1 Conductor, 19 Str...
Regular price
$3.00
Unit price
Description
Description
Alpha Wire 5875 WHT/RED | Hook-up Wire, 22 AWG, 1 Conductor, 19 Stranded, White/Red Spiral Stripe 1000V
Alpha Wire hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.
Specifications
Specifications
Alpha Wire - 5875 WHT/RED - Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 22 (19/34) AWG Silver Plated Copper |
| Temperature Range | -60 to 200°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 5.9 Lbs, Maximum |
| Voltage Rating | 1000 V |
| Inductance | 0.05 ?H/ft, Nominal |
| Conductor DCR | 14 ?/1000ft @20°C, Nominal |
