Alpha Wire 5953 GR001 | Hook Up Wire, 26AWG, 1000 FT, Green
Regular price
$1.46
Unit price
Brand: Alpha Wire
|
SKU:
A5953-5
Regular price
$1.46
Unit price
Description
Description
26 AWG Hook-Up Wire Solid Green 1000.0' (304.8m)
Specifications
Specifications
Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 26 (SOLID) AWG SPC |
| Insulation | 0.0055" Wall, Nom. PVDF |
| Color(s) | WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWNORANGE, SLATE, VIOLET |
| EU Directive 2011/65/EU(RoHS2): | All materials used in the manufacture of this part are in compliance with European Directive 2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and electronic equipment. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| California Proposition 65: | The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -40 to 125°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 1.99 Lbs, Maximum |
| Voltage Rating | NOT SPECIFIED |
| Conductor DCR | 41 ?/1000ft @20°C, Nominal |
