Brand: Alpha Wire
|
SKU:
A6455-2000-DRAKA
Alpha Wire 6455 BK001 | Communication-Control-Industrial-Cable, Industrial Automation, 2 Pair, 22 AWG
Regular price
$4.59
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 6455 BK001 | Communication-Control-Industrial-Cable, Ind...
Regular price
$4.59
Unit price
Brand: Alpha Wire
|
SKU:
A6455-2000-DRAKA
Regular price
$4.59
Unit price
Shipping calculated at checkout.
Description
Description
4 (2 Pair Twisted) Conductor Multi-Pair Cable Black 22 AWG Foil, Braid 1000.0' (304.8m)
Key Features
- Low-loss RG-6/U 75-ohm coaxial cable
- Double braid/foil shielding for maximum signal integrity and run length
Specifications
Specifications
Specifications
| Component 1 | 2 X 1 PAIR |
|---|---|
| Conductor | 22 (7/30) AWG TC |
| Insulation | 0.0245" Wall, Nom. Foam HDPE |
| Pair | 2/Cond Cabled Together |
| Twists: | 4.8 Twists/foot (min) |
| Cable Assembly | 2 Components Cabled |
| Twists: | 3.2 Twists/foot (min) |
| Shield: | Alum/Mylar Tape, 25% Overlap, Min. |
| Foil Direction | Foil Facing Out |
| Drain Wire | 22 (7/30) AWG TC |
| Braid | TC,65% Coverage, Min. |
| Jacket | 0.053" Wall, Nom.,PVC |
| Color(s) | BLACK |
| ALPHA WIRE P/N 6455 2PR 22 AWG EXXXXX SHIELDED (UL) CM OR PLTC SUN RES ORC(UL) CM --- FT1 CE ROHS[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.] | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 60°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 33 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Mutual Capacitance | 11 pf/ft @1 kHz, Nominal |
| Ground Capacitance | 20.9 pf/ft @1 kHz, Nominal |
| Velocity of Propagation | 78 % |
| Conductor DCR | 15.4 ?/1000ft @20°C, Nominal |
| OA Shield DCR | 2.7 ?/1000ft @20°C, Nominal |
| Current | 2.7 amps per conductor @30°C, Maximum |
