Brand: Alpha Wire
|
SKU:
A6710-3/4/7
Alpha Wire 6710 OR001 | EcoWire, 28AWG, (7/36) Stranding, 1000 Ft, Orange
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 6710 OR001 | EcoWire, 28AWG, (7/36) Stranding, 1000 Ft, ...
Regular price
$1.46
Unit price
Brand: Alpha Wire
|
SKU:
A6710-3/4/7
Regular price
$1.46
Unit price
Shipping calculated at checkout.
Description
Description
Alpha Wire 6710 OR001 | EcoWire, 28AWG, (7/36) Stranding, 1000 Ft, Orange
Alpha Wire - 6710 OR001 - Features
- Better dielectric strength
- Wide temperature range that meets VW-1
- Low specific gravity
- Up to 45% smaller diameter
- Up to 40% lighter
- Fully Recyclable
Specifications
Specifications
Alpha Wire - 6710 OR001 - Specifications
| Conductor Material | Tinned Copper |
|---|---|
| Conductor Size | 28 AWG (American Wire Gauge) |
| Insulation Color | Orange |
| Conductor Stranding | 7 Strands In Each Conductor |
| Insulation Material | MPPE-Modified Polyphenylene |
| Product Type | UL Style 10000 Series |
| Shielded | Not Shielded |
| Temperature Rating | 105 Degrees Centigrade (221 F) |
| Ul Style | Ul Type Awm, Style 11028 |
| UNSPSC Code | 26121539 |
| Temperature Range | -40 to 105°C |
| Bend Radius | 5X Cable Diameter |
| Pull Tension | 1.37 Lbs, Maximum |
| Voltage Rating | 600 VRMS |
| Inductance | 0.06 ?H/ft, Nominal |
| Conductor DCR | 65 ?/1000ft @20°C, Nominal |
