Alpha Wire 7132 VI001 | 20 AWG Hook-Up Wire 7/28 Violet 300V 1000.0...
Description
Description
The broad range of hook-up wire from Alpha means you will find the product exactly suited to your application— whether it’s as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high-temperature oven, or off-road construction equipment. Our hook-up wire is available in a variety of insulations to meet your needs for temperature, ability to withstand wear and abrasion, electrical performance, or resistance to oil, solvents, and chemicals.
Specifications
Specifications
Alpha Wire - 7132 VI001 - Specifications
| Component 1 | 1 X 1 HOOKUP |
|---|---|
| Conductor | 20 (7/28) AWG Tinned Copper |
| Temperature Range | -55 to 105°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 8.7 Lbs, Maximum |
| Voltage Rating | 300 V |
| Inductance | 0.05 ?H/ft, Nominal |
| Conductor DCR | 10.1 ?/1000ft @20°C, Nominal |
| Conductor Material | Tinned Copper |
| Conductor Size | 20 Awg (American Wire Gauge) |
| Conductor Stranding | 7 Strands In Each Conductor |
| Insulation Color | Black |
| Insulation Material | Irpvc-irradiated Polyvinyl Chloride |
| Mil Spec | Mil-w-16878/2 (Type C) |
| Product Type | Ul Styles 1000-1999 |
| Rohs Compliant | Yes |
| Shielded | Not Shielded |
| Temperature Rating | 105 Degrees Centigrade (221 F) |
| Unspsc Code | 26121539 |
