Brand: Alpha Wire
|
SKU:
A9432
Alpha Wire 9432 WH033 | 32AWG 50OHM PFA MICRO COAXIAL CABLE WHITE JKT 328’
Regular price
$1,381.63
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 9432 WH033 | 32AWG 50OHM PFA MICRO COAXIAL CABLE WHITE J...
Regular price
$1,381.63
Unit price
Description
Description
Micro Coaxial Cable 32 AWG 328.1' (100.00m) 50 Ohms
Specifications
Specifications
Specifications
| Component 1 | 1 X 1 COAX |
|---|---|
| Conductor | 32 (7/40) AWG Silver Platted Copper |
| Insulation | 0.0083" Wall, Nom. PFA |
| Shield | Silver Platted Copper BRAID Shield,90% Coverage, Min. |
| Jacket | 0.005" Wall, Nom.,PFA |
| Color(s) | WHITE |
| EU Directive 2011/65/EU(RoHS2): | All materials used in the manufacture of this part are in compliance with European Directive 2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and electronic equipment. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -70 to 200°C |
| Bend Radius | 10X Cable Diameter |
| Voltage Rating | 30 VRMS |
| Ground Capacitance | 29.9 pF/ft @1 kHz, Nominal |
| Velocity of Propagation | 70 % |
| Conductor DCR | 168.6 ?/1000ft @20°C, Max |
| Attenuation, Max dB/100ft | 22.9 @ 100 MHz, 48.8 @ 500 MHz |
