Brand: Alpha Wire
|
SKU:
A9434
Alpha Wire 9434 WH033 | 34AWG 50OHM PFA MICRO COAXIAL CABLE WHITE JKT 328’
Regular price
$1,237.17
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire 9434 WH033 | 34AWG 50OHM PFA MICRO COAXIAL CABLE WHITE J...
Regular price
$1,237.17
Unit price
Description
Description
Micro Coaxial Cable 34 AWG 328.1' (100.00m) 50 Ohms
Specifications
Specifications
Specifications
| Component 1 | 1 X 1 COAX |
|---|---|
| Conductor | 34 (7/42) AWG Silver Platted Copper |
| Insulation | 0.0068" Wall, Nom. PFA |
| Shield | Silver Platted Copper BRAID Shield,90% Coverage, Min. |
| Jacket | 0.005" Wall, Nom.,PFA |
| Color(s) | WHITE |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -70 to 200°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 0.34 Lbs, Maximum |
| Voltage Rating | 30 VRMS |
| Ground Capacitance | 29.9 pF/ft @1 kHz, Nominal |
| Velocity of Propagation | 70 % |
| Conductor DCR | 271.9 ?/1000ft @20°C, Nominal |
| Attenuation, Max dB/100ft | 26.5 @ 100 MHz, 63.7 @ 500 MHz |
