Alpha Wire 9446 WH033 | 46AWG 50OHM PFA MICRO COAXIAL CABLE WHITE J...
Regular price
$1,500.15
Unit price
Brand: Alpha Wire
|
SKU:
A9446
Regular price
$1,500.15
Unit price
Description
Description
Micro Coaxial Cable 46 AWG 328.1' (100.00m) 50 Ohms
Specifications
Specifications
Specifications
| Component 1 | 1 X 1 COAX |
|---|---|
| Conductor | 46 (7/5AWG Silver Copper Alloy |
| Insulation | 0.0013" Wall, Nom. PFA |
| Shield | Silver Platted Copper Alloy SPIRAL Shield,90% Coverage, Min. |
| Jacket | 0.0009" Wall, Nom.,PFA |
| Color(s) | WHITE |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -70 to 200°C |
| Bend Radius | 10X Cable Diameter |
| Voltage Rating | 30 VRMS |
| Characteristic Impedance | 50 ? +/- 5 |
| Velocity of Propagation | 69 % |
| Conductor DCR | 4724.4 ?/1000ft @20°C, Max |
| Attenuation, Max dB/100ft | 42.7 @ 10 MHz |
