Brand: Alpha Wire
|
SKU:
M3232
Alpha Wire M3232 SL001 | COMPOSITE CABLE, 20 AWG - 2 CONDUCTOR STRANDED TNC PE FOIL SHIELD, PVC JACKET CHR GREY, CM 300V 75 CONDUCTOR ROHS
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Alpha Wire M3232 SL001 | COMPOSITE CABLE, 20 AWG - 2 CONDUCTOR STRA...
Regular price
$1.46
Unit price
Description
Description
2 Conductor Multi-Conductor Cable Slate 20 AWG Foil 1000.0' (304.8m)
Key Features
- Audio systems: speakers, microphones, intercoms
- Broadcast and studio
- Data transmission: RS-232, 422, 485
- CAD/CAM
- Computer peripherals
- Business machines
- Security systems: alarms, cameras, sensors
- Control systems
- Instrumentation systems
- Point-of-sale systems
- Banking systems
Specifications
Specifications
Specifications
| Component 1 | 2 X 1 COND |
|---|---|
| Conductor | 20 (7/28) AWG Tinned Copper |
| Insulation | 0.016" Wall, Nom. FRPE |
| Color Code | Alpha Wire Color Code D |
| Cable Assembly | 2 Components Cabled |
| Twists: | 6.0 Twists/foot (min) |
| Orientation: | Components to be arranged from INSIDE LAYER to OUTSIDE LAYER |
| Shield: | Alum/Mylar Tape, 25% Overlap, Min. |
| Foil Direction | Foil Facing Out |
| Drain Wire | 20 (7/28) AWG Tinned Copper |
| Jacket | 0.020" Wall, Nom.,PVC |
| Color(s) | SLATE |
| ALPHA WIRE-* P/N M3232 2C 20 AWG EXXXXXX 75C SHIELDED CMG (UL) C(UL) FT4OR AWM STYLE 2092 CE ROHS* = Factory Code[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.] | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011and the amending Directive 2015/863/EU of 4 June 2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 75°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 26 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Ground Capacitance | 47 pF/ft @1 kHz, Nominal |
| Characteristic Impedance | 63 ? |
| Inductance | 0.19 µH/ft, Nominal |
| Conductor DCR | 10.2 ?/1000ft @20°C, Nominal |
| OA Shield DCR | 8.2 ?/1000ft @20°C, Nominal |
