Alpha Wire M38902 | 2 Conductor Multi-Conductor Cable Slate 24 AWG
Regular price
$1.46
Unit price
Brand: Alpha Wire
|
SKU:
M38902
Regular price
$1.46
Unit price
Description
Description
Alpha Wire M38902 - CABLE CMG - 24-2C STR TNC PVC PVC JKT GRY
Key Features
- Audio systems: speakers, microphones, intercoms
- Broadcast and studio
- Data transmission: RS-232, 422, 485
- CAD/CAM
- Computer peripherals
- Business machines
- Security systems: alarms, cameras, sensors
- Control systems
- Instrumentation systems
- Point-of-sale systems
- Banking systems
Specifications
Specifications
Specifications
| Component 1 | 2 X 1 COND |
|---|---|
| Conductor | 24 (7/32) AWG TC |
| Insulation | 0.010" Wall, Nom. PVC, Semi Rigid |
| Color Code | Alpha Wire Color Code E |
| Cable Assembly | 2 Components Cabled |
| Twists: | 9.6 Twists/foot (min) |
| Core Wrap | Clear Mylar Tape, 25% Overlap, Min. |
| Jacket | 0.032" Wall, Nom.,PVC |
| Color(s) | SLATE |
| ALPHA WIRE-* P/N M38902 2C 24 AWG EXXXXXXX 75C CMG(UL) C(UL) ORAWM STYLE 2464 CE ROHS* = Factory Code[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.] | |
| CE: EU Directive 2011/65/EU(RoHS2): | This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C. |
| REACH Regulation (EC 1907/2006): | This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. |
| California Proposition 65: | The outer surface materials used in the manufacture of this part meet the requirements of California Proposition 65. |
| Packaging | Flange x Traverse x Barrel (inches) |
| Temperature Range | -20 to 80°C |
| Bend Radius | 10X Cable Diameter |
| Pull Tension | 10.6 Lbs, Maximum |
| Voltage Rating | 300 VRMS |
| Inductance | 0.19 µH/ft, Nominal |
| Conductor DCR | 26 ?/1000ft @20°C, Nominal |
