Altronix AF80N3-30-11-11 | Long Range Single Pair (UTP) Ethernet Adapter/Transceiver
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix AF80N3-30-11-11 | Long Range Single Pair (UTP) Ethernet Ad...
Description
Description
Altronix Pace1KT is a long-range Ethernet adapter/transceiver that transmits data and power from Pace1KR or Pace4KR(Q) receivers via twisted pair (2-wire, UTP or shielded) in a PoE(+) compliant format. In addition to new SPE (UTP) Ethernet network installations for Surveillance-cameras/Security/Industrial/BMS/HVAC & Elevator Controllers, applications include upgrading of legacy networks, i.e. LONworks, RS485, 4-20ma Control Loops, etc. by using the existing two wire cabling, thus saving rip-out & reinstallation costs.
Operationally, Pace1KR or Pace4KR(Q) is connected to a PoE midspan/endspan switch at the headend and passes network data and power to the Pace1KT from the switch via UTP up to 1km (1,000m, 3,280 ft.) to a remote 10/100 PoE device, such as a camera. For non-PoE remote devices, data only is transmitted.
Altronix - PACE1KT - Features
- UTP Connection
- Wire type: Twisted pair (2-wire, UTP or shielded)
- Distance: 1km (1,000m, 3,280 ft.), 16/2 AWG or higher @ 10Mbps
- Connectivity: RJ45, auto-crossover.
- Wire type: 4-pair CAT5e or higher.
- Distance: up to 100m from midspan to Pace1KR receiver (headend), 100m from PaceKT transceiver to device
- Speed: 10/100BaseT, half/full duplex, auto negotiation. PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (25W) delivered to device by Pace KR receiver.
- Power provided by Pace KR receiver to Pace1KT by PoE protocol.
- Green LED (left): PoE (link)
- Green LED (right): Data transmission (link)
- Yellow and Green LED (by RJ45 jack): IP Link status, 10/100Base-T/active
- Auto detection and protection of legacy non-PoE cameras/devices.
Altronix - PACE1KT - Features
| Altronix AF80N3-30-11-11 Data Sheet | Click to View |
|---|
Specifications
Specifications
Altronix - PACE1KT - Input
- Powered by Pace KR receiver
- PoE compliant to IEEE 802.3af (15W) and PoE+ compliant to IEEE 802.3at (30W).
Altronix - PACE1KT - Specifications
| Operating | – 40ºC to 75ºC (– 40º to 167ºF) |
|---|---|
| Storage | – 40ºC to 75ºC (– 40º to 167ºF) |
| Relative Humidity | 85% +/– 5% |
| Operating Altitude | -304.8 to 2000m. |
| Enclosure | Modular plastic case. |
| Dimensions | 2.27"W x 1.12"H x 2.64"D (57.66 mm W x 28.44 mm H x 67.18 mm D). |
