Altronix AL1012X220 | Power Supply Charger, Single Fused Output, 12vdc @ 10a, 220vac, Bc400 Enclosure

Altronix - AL1012X220 - Features

• Input
• Nominal 220VAC (range 198VAC-256VAC), 50/60Hz, 1.3A
• Input fuse rated @ 5A/250V
• Output
• 12VDC output
• 10A continuous supply current
• Output fuse rated @ 15A/32V
• Filtered and electronically regulated output
• Short circuit and thermal overload protection
• Battery Backup
• Built-in charger for sealed lead acid or gel type batteries
• Automatic switch over to stand-by battery when AC fails
• Supervision
• AC fail supervision (form "C" contacts)
• Notification trigger is selectable for 30 seconds (factory set) or 6 hours
• Low battery supervision (form "C" contacts)
• Battery presence supervision (form "C" contacts)
• Visual Indicators
• AC input and DC output LED indicators
• Temperature
• Operating 0 to 49° C (32 to 120° F )
• Storage - 20 to 70° C ( - 4 to 158° F)
• Relative Humidity 85% +/- 5%
• BTU/Hr. (approx.): 61 BTU/Hr
• System AC input VA requirement: 286VA
