Brand: Altronix
|
SKU:
10266073
Altronix AL1024NK8QP | Networked Dual Voltage Power Supply/Charger, BC400 Enclosure
Regular price
$856.56
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix AL1024NK8QP | Networked Dual Voltage Power Supply/Charger,...
Regular price
$856.56
Unit price
Description
Description
Altronix AL1024NK8QP | Networked Dual Voltage Power Supply/Charger, BC400 Enclosure
Input Fuse: 5A / 250V.
Current: 10A @ 24VDC continuous max.
Protection: Overvoltage protection. Filtered and regulated.
Type: Sealed lead acid or gel type.
Failover: Upon AC loss, instantaneous.
Battery: Form “C” contacts.
DC Output: Powered.
Battery: Discharged or not connected.
Current: 6A continuous.
Other: Surge suppression.
Output: Powered.
Input Fuses: 15A/32V.
Power output(s) can be locally or remotely controlled.
Surge suppresion.
Output Fuses: 3A/32V.
Voltage and load of each output.
FACP trigger and reset status.
Unit temperature (Celsius).
Power Supply AC and Battery status.
Battery health.
FACP: Triggered / Released.
Input: Input signal.
Out1 - Out8: Bi-colored LEDs indicate 12 or 24VDC.
E-mail notifications.
Event Log tracks history.
FACP trigger type (wet or dry-N.O./N.C.).
Input Function (FACP reset/tamper).
Output Reset Trigger (N.O./N.C.).
- Service Date.
Configurable Output Relay(s).
- Voltage and Current Limits (High/Low).
- FACP Trigger Setting (latching/non-latching/inactive).
- Battery Backup.
FACP reset (N.C. or N.O.).
Storage: - 20° C to 70° C ( - 4° F to 158° F).
AL1024ULXB2 Power Supply/Charger / Input
Voltage: 115VAC, 60Hz, 4.2A max.Input Fuse: 5A / 250V.
Outputs
Voltage: 24VDC.Current: 10A @ 24VDC continuous max.
Protection: Overvoltage protection. Filtered and regulated.
Battery Backup
Capacity: 12AH /12VDC (2 within enclosure); 40 AH / 65 AH (requires separate enclosure).Type: Sealed lead acid or gel type.
Failover: Upon AC loss, instantaneous.
Supervision
AC Failure: Form “C” contacts.Battery: Form “C” contacts.
Indicators LED
Input: 115VAC is present.DC Output: Powered.
Battery: Discharged or not connected.
VR6 Voltage Regulator / Input
Voltage: 24VDC from AL1024ULXB2.Output
Voltage: 12VDC.Current: 6A continuous.
Other: Surge suppression.
Indicators LED
Input: 24VDC is present.Output: Powered.
LINQ8PD Network Power Distribution Module / Input
Voltage: 24VDC from AL1024ULXB2 and 12VDC from VR6.Input Fuses: 15A/32V.
Outputs
Eight (8) fuse protected outputs rated 2.5A.Power output(s) can be locally or remotely controlled.
Surge suppresion.
Output Fuses: 3A/32V.
Status Monitoring
Power Supply output voltage and load.Voltage and load of each output.
FACP trigger and reset status.
Unit temperature (Celsius).
Power Supply AC and Battery status.
Battery health.
Indicators (LED)
Bat Local: Charging current status.FACP: Triggered / Released.
Input: Input signal.
Out1 - Out8: Bi-colored LEDs indicate 12 or 24VDC.
Reporting
Windows Dashboard Alert messages.E-mail notifications.
Event Log tracks history.
Programming Features
Power Supply(ies) voltage and load limits (High/Low).FACP trigger type (wet or dry-N.O./N.C.).
Input Function (FACP reset/tamper).
Output Reset Trigger (N.O./N.C.).
Battery Monitor Configuration:
- Battery condition (Low/Normal/Missing).- Service Date.
Configurable Output Relay(s).
Individual Output Configuration:
- Device ID.- Voltage and Current Limits (High/Low).
- FACP Trigger Setting (latching/non-latching/inactive).
- Battery Backup.
Fire Alarm Interface
Supervised FACP disconnect (Latching or Non-Latching).FACP reset (N.C. or N.O.).
Environmental / Temperature
Operating: 0° C to 49° C (32° F to 120° F).Storage: - 20° C to 70° C ( - 4° F to 158° F).
Relative Humidity
Relative Humidity 85% +/- 5%.BTU/Hr (approx.):
123 BTU/Hr.Overview
- Altronix AL1024NK8QP sub-assembly kit converts a 115VAC 60Hz input into eight (8) fuse protected outputs. Outputs are individually selectable, providing 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) for access control panels, door locks, and ancillary devices. Unit also offers a suite of features that includes overvoltage protection, AC fail supervision, low battery supervision and battery presence supervision. Networkable power distribution module facilitates monitoring, reporting, and control of the supervised DC power supply/charger over the network. It reports diagnostics via Email and Windows Dashboard Alert notifications, greatly reducing system downtime and eliminating unnecessary service calls.
Specifications
Specifications
Altronix - AL1024NK8QP - Overview
- Altronix AL1024NK8QP sub-assembly kit converts a 115VAC 60Hz input into eight (8) fuse protected outputs. Outputs are individually selectable, providing 12VDC or 5VDC up to 6A and/or 24VDC up to 10A (240W total power) for access control panels, door locks, and ancillary devices. Unit also offers a suite of features that includes overvoltage protection, AC fail supervision, low battery supervision and battery presence supervision. Networkable power distribution module facilitates monitoring, reporting, and control of the supervised DC power supply/charger over the network. It reports diagnostics via Email and Windows Dashboard Alert notifications, greatly reducing system downtime and eliminating unnecessary service calls.
Altronix - AL1024NK8QP - Product Categories
- Industrial
- Electrical Enclosures
- Electrical Enclosures
Altronix - AL1024NK8QP - Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | AL1024NK8QP |
| Item Description | Networked Dual Voltage Power Supply/Charger, BC400 Enclosure |
| Agency Listings | CE Compliant |
| UNSPSC Code | 24102001 |
| Weights (approximate): | - |
| Product Weight: | 9.4 Lbs. |
| (4.26 kg). | Shipping Weight: |
| 10.5 Lbs. | (4.76 kg). |
