Altronix AL600PD8CB220 | Power Supply Charger, 8 Ptc Class 2 Outputs, 12/24vdc @ 6a, 220vac, Bc300 Enclosure

Altronix - AL600PD8CB220 - Features

• Input
• Nominal 220VAC (range 198VAC-256VAC), 50/60Hz, 1.5A
• Output
• 12VDC or 24VDC selectable output
• 6A continuous supply current
• Eight (8) PTC protected outputs (auto-resettable)
• Outputs are rated @ 2.5A
• Filtered and electronically regulated output
• Short circuit and thermal overload protection
• Battery Backup
• Built-in charger for sealed lead acid or gel type batteries
• Automatic switch over to stand-by battery when AC fails
• Supervision
• AC fail supervision (form "C" contacts)
• Notification trigger is selectable for 30 seconds (factory set) or 6 hours
• Low battery supervision (form "C" contacts)
• Battery presence supervision (form "C" contacts)
• Visual Indicators
• AC input, DC output and BAT trouble
• Temperature
• Operating 0 to 49° C (32 to 120° F )
• Storage - 20 to 70° C ( - 4 to 158° F)
• Relative Humidity 85% +/- 5%
• BTU/Hr. (approx.)
• 12VDC or 12VAC: 37 BTU/Hr
• 24VDC or 24VAC: 74 BTU/Hr
