Brand: Altronix | SKU: 231044

Altronix ALTV1224DC | CCTV Power Supply, 8 Fused Outputs, 12/24VDC @ 4A, 115VAC, BC300 Enclosure

$255.56

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

ALTV1224DC is designed to power CCTV Cameras and accessories. It will provide 12VDC or 24VDC distributed via eight (8) fuse protected outputs with a total of 4A total supply current.

Main Features

AC input and DC output LED indicators.
Power ON/OFF switch.
Ease of installation saves time and eliminates costly labor.

Specifications

Enclosure

Wall mount enclosure for indoor use.
Dimensions 13"W x 13.5"H x 3.25"D (330 mm W x 343 mm H x 83 mm D).
1/2" and 3/4" combination knockouts.

Input

Input 115VAC, 50/60 Hz, 1.45A.

Output

Eight (8) fuse protected outputs.
12VDC or 24VDC field adjustable.
4A total continuous supply current (0.5A per device, 3.5A max.).
Outputs are rated @ 3.5A.
Filtered and electronically regulated outputs.

Electrical

Temperature:
Operating: 0° C to 49° C (32° F to 120° F).
Storage: - 20° C to 70° C ( - 4° F to 158° F).
Relative Humidity 85% +/- 5%
BTU/Hr (approx.):
12VDC: 25 BTU/Hr.
24VDC: 49 BTU/Hr.
System AC input VA requirement: 166.75VA.

Weights (approximate)

Product Weight	7.8 Lbs. (3.54 kg).
Shipping Weight	8.7 Lbs. (3.95 kg).

Documents and Downloads
