Altronix EFLOW102NBV | Power Supply Charger, Single Output, 12vdc @ 10a, Aux Output, Fai, Linq2 Ready, 220vac, Board

Altronix - EFLOW102NBV - Features

• Short circuit and overload protection
• Input Rating
• Input 220VAC (working range 198VAC - 256VAC), 50/60Hz, 2.1A
• Output
• 12VDC output
• 10A continuous supply current
• Aux. output rated @ 1A (unswitched)
• Overvoltage protection
• Filtered and electronically regulated outputs
• Battery Backup
• Built-in charger for sealed lead acid or gel type batteries
• Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous with no interruption
• Fire Alarm Disconnect
• Supervised Fire Alarm disconnect (latching or nonlatching) 10K EOL resistor. Operates on a normally open (NO) or normally closed (NC) trigger
• Supervision
• AC fail supervision (form "C" contacts)
• Notification trigger is selectable for 30 seconds (factory set) or 2 hours
• Battery fail and presence supervision (form "C" contacts)
• Low power shutdown. Shuts down DC output terminals if battery voltage drops below 80% of nominal. Prevents deep battery discharge
• Electrical
• Temperature
• Operating: 0° C to 49° C (32° F to 120° F)
• Storage: - 20° C to 70° C ( - 4° F to 158° F)
• Relative Humidity 85% +/- 5%
• BTU/Hr (approx.): 61 BTU/Hr
• System AC input VA requirement: 462VA
• Visual Indicators
• Green AC Power LED indicates 220VAC present
• AC input and DC output LED indicators
