Altronix EFLOW104N16DV | Eflow104n With Pd16cb 220v
Regular price
$483.16
Unit price
Brand: Altronix
|
SKU:
1052582
Regular price
$483.16
Unit price
Description
Description
Altronix EFLOW104N16DV | Power Supply Charger, 16 PTC Class 2 Outputs, 24VDC @ 10A
Altronix eFlow104N16DV is a power supply/charger that converts a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) PTC protected 24VDC outputs with a total of 10A max. The unit includes an unswitched aux. output. It also offers a suite of features that includes fire alarm disconnect, overvoltage protection, and low power disconnect which prevents deep discharge of stand-by batteries.
Altronix - EFLOW104N16DV - Features
- Short circuit and overload protection
- Unit is complete with power supply, enclosure, battery leads, and cam lock
- Input
- 220VAC (working range 198VAC - 256VAC), 50/60Hz, 2.7A
- Input fuse: 5A/250V
- Output
- Sixteen (16) PTC protected outputs (auto-resettable)
- Outputs are rated @ 2A
- 24VDC @ 10.0A supply current
- Auxiliary output rated @ 1A (unswitched)
- Overvoltage protection
- Battery Backup
- Built-in charger for sealed lead acid or gel type batteries
- Automatic switch over to stand-by battery when AC fails. Transfer to stand-by battery power is instantaneous with no interruption
- Supervision
- AC fail supervision (form "C" contacts)
- Notification trigger is selectable for 30 seconds (factory set) or 2 hours
- Battery fail and presence supervision (form "C" contacts)
- Low power shutdown. Shuts down DC output terminals if battery voltage drops below 70-75% (depending on the power supply). Prevents deep battery discharge
- Fire Alarm Disconnect
- Supervised Fire Alarm disconnect (latching or non-latching) 10K EOL resistor. Operates on a normally open (NO) or normally closed (NC) trigger
- Electrical
- Temperature
- Operating: 0° C to 49° C (32° F to 120° F)
- Storage: - 20° C to 70° C ( - 4° F to 158° F)
- Relative Humidity 85% +/- 5%
- BTU/Hr (approx.): 123 BTU/Hr
- System AC input VA requirement: 594VA
- Visual Indicators
- Green AC Power LED indicates 220VAC present
- AC input and DC output LED indicators
Specifications
Specifications
Altronix - EFLOW104N16DV - Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | EFLOW104N16DV |
| Item Description | Power Supply Charger, 16 PTC Class 2 Outputs, 24VDC @ 10A |
