Altronix MAXIMAL75FEV | Power Supply/charger, Expandable, 1 P/s 24vdc @ 10a & 1 P/s 24vdc @ 10a, Fai, Linq2 Ready, 220vac, Bc800 Enclosure

Altronix - MAXIMAL75FEV - Features

• Input
• 220VAC (working range 198VAC - 256VAC), 50/60Hz, 4.8A input
• Output
• 12VDC and 24VDC outputs
• Maximum output current Options:
• A) 24VDC @ 10A plus 12VDC @ 10A
• Aux. output rated @ 1A (unswitched)
• Overvoltage protection
• Fuse Ratings
• Power Supply input fuse rated @ 5A/250V
• Fire Alarm Disconnect
• Supervised Fire Alarm disconnect (latching or non-latching) 10K EOL resistor. Operates on a normally open (NO) or normally closed (NC) trigger
• Supervision
• AC fail supervision (form "C" contacts)
• Notification trigger is selectable for 30 seconds (factory set) or 2 hours
• Battery fail & presence supervision (form "C" contacts)
• Low power shutdown. Prevents deep battery discharge
• Battery Backup
• Built-in charger for sealed lead acid or gel type batteries
• Automatic switch over to stand-by battery when AC fails
• Battery fuses rated @ 15A/32V
• Visual Indicators
• Green AC Power LED indicates 220VAC present
• AC input and DC output LED indicators
• Temperature
• Operating Temperature: 0° C to 49° C ambient
• Storage Temperature: - 20ºC to 70ºC ( - 4ºF to 158ºF)
• Relative Humidity 85% +/- 5%
• BTU/Hr (approx.): 184 BTU/Hr
• System AC input VA requirement: 1056VA
