Brand: Altronix
|
SKU:
720433-NOM
Altronix NETWAY16G | Network Managed PoE Midspan, 16 Port, 10/100/1000, 30W per port (480W total power), Battery Charging, 115/230VAC Input
Regular price
$1,230.54
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix NETWAY16G | Network Managed PoE Midspan, 16 Port, 10/100/1...
Regular price
$1,230.54
Unit price
Brand: Altronix
|
SKU:
720433-NOM
Regular price
$1,230.54
Unit price
Shipping calculated at checkout.
Description
Description
Altronix NetWay16G is a 16-port networked Managed Midspan in a 1U rack enclosure. It provides PoE/PoE+ (up to 30W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup and embedded LINQ™ Technology to monitor, control, and report power and diagnostics from anywhere.
Specifications
Specifications
Enclosure
- Modular 1U standard EIA 19" rack mount chassis.
- Dimensions 19.12"W x 1.62"H x 8.5"D (486 mm W x 42 mm H x 216 mm D).
Input
- 115VAC, 60Hz, 4.5A or 230VAC, 50/60Hz, 3A.
Power
- Unit supplies PoE output voltage (55V) and up to 30W max. full power per port.
- Total power: NetWay16G - 480W
- IEEE 802.3af and IEEE 802.3at compliant (PoE/PoE+).
- Short circuit protection.
Ethernet:
- Sixteen (16) ports for cameras/edge devices over ethernet.
- Wire type: 4-pair CAT5e and higher.
- Speed: 10/100/1000 Mbps.
Functions
- Auto detection and protection of legacy non-PoE cameras/edge devices.
Visual Indicators
- Yellow and Green LED (by RJ45 jack): IP Link status, 10/100/1000 Base-T/active.
- Green LED: Port status.
Weights (approximate)
| Product Weight | 4.05 Lbs. (1.84 kg). |
|---|---|
| Shipping Weight | 5.1 Lbs. (2.31 kg). |
Agency Listings
| UL Listed For: Information Technology Equipment (UL60950-1) | https://iq.ulprospector.com/en/profile?e=3010301 |
|---|---|
| cUL Listed For: Information Technology Equipment | https://iq.ulprospector.com/en/profile?e=2998313 |
