Brand: Altronix
|
SKU:
10344005
Altronix NETWAY81GP | PoE Midspan, 8 Port, 10/100/1000, 60W max per port (480W total power), Battery Charging, 115/230VAC Input
Regular price
$1,395.45
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix NETWAY81GP | PoE Midspan, 8 Port, 10/100/1000, 60W max per...
Regular price
$1,395.45
Unit price
Description
Description
Altronix NETWAY81GP | PoE Midspan, 8 Port, 10/100/1000, 60W max per port (480W total power), Battery Charging, 115/230VAC Input
60W full power per port.
Total power: 480W.
Wire type: 4-pair CAT5e or better structured cable
Distance: up to 100m
Speed: 10/100/1000 BaseT, half/full duplex, auto negotiation
Storage: - 20º to 70ºC ( - 4ºF to 158ºF).
Relative Humidity 85% +/- 5%.
BTU/Hr. (approx.): 500 BTU/Hr.
Input
115VAC, 60Hz, 5.5A or 230VAC, 50H/60z, 3.0A.Power
Unit provides PoE / PoE+ / Hi PoE.60W full power per port.
Total power: 480W.
Ethernet
Connectivity: RJ45, auto-crossoverWire type: 4-pair CAT5e or better structured cable
Distance: up to 100m
Speed: 10/100/1000 BaseT, half/full duplex, auto negotiation
Indicators (LED) / Yellow and Green LED (by RJ45 jack)
IP Link status, 10/100/1000 Base-T/activeGreen LED
Port statusTemperature
Operating: - 20ºC to 50ºC ( - 4ºF to 122ºF).Storage: - 20º to 70ºC ( - 4ºF to 158ºF).
Relative Humidity 85% +/- 5%.
BTU/Hr. (approx.): 500 BTU/Hr.
Operating Altitude
Up to 2,000m.Overview
- Altronix NetWay81GP is an 8-port midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE (up to 60W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup.
Specifications
Specifications
Altronix - NETWAY81GP - Overview
- Altronix NetWay81GP is an 8-port midspan in a 1U rack enclosure. It provides PoE/PoE+/Hi PoE (up to 60W power per port), and passes data at 10/100/1000 Mbps at distances up to 100m. Features also include an integral battery charger for applications requiring backup.
Altronix - NETWAY81GP - Product Categories
- Security
- Access Control
- Panels
Altronix - NETWAY81GP - Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | NETWAY81GP |
| Item Description | PoE Midspan, 8 Port, 10/100/1000, 60W max per port (480W total power), Battery Charging, 115/230VAC Input |
| Agency Listings | CE Compliant |
| UNSPSC Code | 43211700 |
| Weights (approximate): | - |
| Product Weight: | 6.17 Lbs. |
| (2.8 kg). | Shipping Weight: |
| 7.5 Lbs. | (3.4 kg). |
