Brand: Altronix
|
SKU:
742803
Altronix OLS250220 | 24vdc 10a Power Supply Board
Regular price
$292.80
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix OLS250220 | 24vdc 10a Power Supply Board
Regular price
$292.80
Unit price
Description
Description
Altronix OLS250220 | Power Supply Charger, Single Output, 24VDC @ 10A, 220VAC, Board
Altronix OLS250220 power supply/charger converts a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into a 24VDC output @ 10A continuous supply current (see specifications). This unit has a wide range of applications for access control and security system accessories that require additional power.
Altronix - OLS250220 - Features
- Input
- 220VAC (working range 198VAC-256VAC), 50/60Hz, 0.95A
- Output
- 24VDC output
- 10A continuous supply current
- Filtered and electronically regulated output
- Short circuit and thermal overload protection
- Battery Backup
- Built-in charger for sealed lead acid or gel type batteries
- Automatic switch over to stand-by battery when AC fails
- Supervision
- AC fail supervision (form "C" contacts)
- Low battery supervision (form "C" contacts)
- Visual Indicators
- AC input and DC output LED indicators
- Features
- Power ON/OFF switch
- Includes battery leads
- Electrical
- Temperature:
- Operating: 0° C to 49° C (32° F to 120° F)
- Storage: - 20° C to 70° C ( - 4° F to 158° F)
- Relative Humidity 85% +/- 5%
- BTU/Hr (approx.): 123 BTU/Hr
- System AC input VA requirement: 209VA
Specifications
Specifications
Altronix - OLS250220 - Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | OLS250220 |
| Item Description | Power Supply Charger, Single Output, 24VDC @ 10A, 220VAC, Board |
