Brand: Altronix
|
SKU:
10386582
Altronix R248600220 | CCTV Power Supply, 8 Fused Outputs, 24/28VAC @ 28A, 220VAC, 2U
Regular price
$775.23
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Altronix R248600220 | CCTV Power Supply, 8 Fused Outputs, 24/28VAC ...
Regular price
$775.23
Unit price
Description
Description
Altronix R248600220 | CCTV Power Supply, 8 Fused Outputs, 24/28VAC @ 28A, 220VAC, 2U
24VAC @ 25A (600VA) supply current (3.125A per device, 3.5A max.) or 28VAC @ 20A (560VA) supply current (2.5A per device, 3.5A max.).
Outputs are rated @ 3.5A.
Surge suppression.
Storage: - 20° C to 70° C ( - 4° F to 158° F).
Relative Humidity 85% +/- 5%.
28VDC: 287 BTU/Hr.
System AC input VA requirement: 660VA.
Illuminated master power disconnect circuit breaker with manual reset.
3-wire grounded line cord.
Removable terminal blocks with locking screw flange.
Spare fuses provided.
Input
220VAC, 50/60Hz, 3A.Output
Eight (8) fuse protected outputs.24VAC @ 25A (600VA) supply current (3.125A per device, 3.5A max.) or 28VAC @ 20A (560VA) supply current (2.5A per device, 3.5A max.).
Outputs are rated @ 3.5A.
Surge suppression.
Electrical / Temperature:
Operating: 0° C to 49° C (32° F to 120° F).Storage: - 20° C to 70° C ( - 4° F to 158° F).
Relative Humidity 85% +/- 5%.
BTU/Hr (approx.):
24VDC: 307 BTU/Hr.28VDC: 287 BTU/Hr.
System AC input VA requirement: 660VA.
Features
Eight (8) power LEDs.Illuminated master power disconnect circuit breaker with manual reset.
3-wire grounded line cord.
Removable terminal blocks with locking screw flange.
Spare fuses provided.
Overview
- R248600220 provides 24VAC or 28VAC distributed via eight (8) fuse protected outputs for powering CCTV Cameras, heaters and other video accessories.
Specifications
Specifications
Altronix - R248600220 - Overview
- R248600220 provides 24VAC or 28VAC distributed via eight (8) fuse protected outputs for powering CCTV Cameras, heaters and other video accessories.
Altronix - R248600220 - Product Categories
- Security
- Access Control
- Power Supplies
Altronix - R248600220 - Specifications
| Brand Name | Altronix |
|---|---|
| Manufacturer Part Number | R248600220 |
| Item Description | CCTV Power Supply, 8 Fused Outputs, 24/28VAC @ 28A, 220VAC, 2U |
| Agency Listings | CE Compliant |
| Sales Category | Power Supply |
| UNSPSC Code | 43211700 |
| Weights (approximate): | - |
| Product Weight: | 23 Lbs. |
| (10.43 kg). | Shipping Weight: |
| 24 Lbs. | (10.89 kg). |
