Altronix T1618300 | Open Frame Transformer, 16/18VAC @ 300VA, 115VAC
Regular price
$245.64
Unit price
Brand: Altronix
|
SKU:
10216375
Regular price
$245.64
Unit price
Description
Description
Altronix T1618300 | Open Frame Transformer, 16/18VAC @ 300VA, 115VAC
Altronix T1618300 open frame transformer provides power for electronic power supplies and equipment including security, access control, and surveillance devices.
Altronix T1618300 open frame transformer provides power for electronic power supplies and equipment including security, access control, and surveillance devices.
Altronix - T1618300 - Features and Specifications
- INPUT
- 115VAC 50/60 Hz, 2.7A.
- OUTPUT
- 16VAC/300VA (18.7A) or 18VAC/300VA (16.7A) supply current.
Specifications
Specifications
Altronix - T1618300 - Dimensions (approximate)
- 5"W x 5"L x 3.35"H (127 mm W x 127 mm L x 85.1 mm H).
Altronix - T1618300 - Temperature
- Operating: 0° C to 49° C (32° F to 120° F).
- Storage - 20° C to 70° C ( - 4° F to 158° F).
- Relative Humidity 85% +/- 5%.
- BTU/Hr (approx.): 154 BTU/Hr.
Altronix - T1618300 - Specifications
| Sales Category | TRANSFORMER |
|---|---|
| UNSPSC Code | 43211700 |
| Agency Listing | CE Compliant |
Altronix - T1618300 - Weights (approximate)
| Product Weight: | 6.95 Lbs. (3.15 kg). |
|---|---|
| Shipping Weight | 7.55 Lbs. (3.42 kg). |
