Brand: Altronix | SKU: 368418-DEMO

Altronix T2428300 | Open Frame Transformer, 24/28VAC @ 300VA, 115VAC

$207.24

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Altronix T2428300 open frame transformer provides power for electronic power supplies and equipment including security, access control, and surveillance devices.

Specifications

Dimensions (approximate)

3.25"W x 5.1"L x 5.15"H (82.55 mm W x 129.54 mm L x 130.81 mm H).

Input

115VAC 50/60 Hz, 2.7A.

Output

24VAC/300VA (14A) or 28VAC/300VA (12.5A) supply current.

Temperature

Operating: 0° C to 49° C (32° F to 120° F).
Storage - 20° C to 70° C ( - 4° F to 158° F).
Relative Humidity 85% +/- 5%.
BTU/Hr (approx.): 154 BTU/Hr.
System AC input VA requirement: 310.5VA.

Weights (approximate)

Product Weight	6.95 Lbs. (3.15 kg).
Shipping Weight	7.55 Lbs. (3.42 kg).

Documents and Downloads
