Altronix T2PHK77F24 | 24-Door Altronix/Openpath Access and Power Integration Kit with Fused Outputs - Trove2CV2 with Two (2) eFlow104NB, Three (3) ACM8. Trove2 Series

Altronix T2PHK77F24 | 24-Door Altronix/Openpath Access and Power Integration Kit with Fused Outputs - Trove2CV2 with Two (2) eFlow104NB, Three (3) ACM8. Trove2 Series

Two (2) eFlow104NB Power Supply/Chargers / Input

Voltage: 120VAC, 60Hz, 9A max.
Input Fuse: 6.3A / 250V.

Output

Voltage: 24VDC 10A.
Auxiliary: 1A (unswitched).
Protection: Overvoltage protection. Filtered and regulated.

Battery Backup

Type: Sealed lead acid or gel type.
Fuse Rating: 15A @ 32VDC.
Failover: Upon AC loss, instantaneous.

Fire Alarm Disconnect

Supervised: Latching or non latching.
EOL: 10K Resistor.

Supervision

AC Failure: Form “C” contacts.
Battery: Form “C” contacts.
Low DC Power Shutdown: Shuts down DC output terminals if battery voltage drops below 70-75% for 24V units (depending on the power supply). Prevents deep battery discharge.

Indicators LED

AC Input: 120VAC is present.
DC Output: Powered.
Battery: Discharged or not connected.

Three (3) ACM8 Access Power Controllers / Input

Voltage: 24VDC from eFlow104NB.
Input Fuse: 10A / 250V.

Outputs

Voltage: 24VDC.
Eight (8) 24VDC independently controlled fused outputs:
a) Fail-Safe and/or Fail-Secure power outputs. Form “C” Relays rated 28VAC or VDC @ 2.5A.
b) Auxiliary power outputs (unswitched).
c) Any combination of the above.
Output Fuses: 3.5A/250V.

Indicators (LED's)

Red LEDs: Outputs are triggered (relays energized).
Green LED: FACP disconnect is triggered.

Environmental / Temperature

Operating: 0° C to 49° C (32° F to 120° F).
Storage: - 20° C to 70° C ( - 4° F to 158° F).

Relative Humidity

Relative Humidity 85% +/- 5%.

BTU/Hr (approx.):

24VDC: 290 BTU/Hr.
12VDC and 24VDC: 111 BTU/Hr.
