American Fibertek MR-940C | 4 Ch Digital Video 10 Bit Module Receiver
Four Channel Digital Video 10 Bit Module Rx - Single Fiber 1310nm 12dB 4Km MM.
Four channels of highquality digitized video on one multimode optical fiber. Designed to be completely transparent to all camera and monitor manufacturers, this system requires no field adjustments at installation or additional maintenance thereafter. Diagnostic indicators provide a quick visual indication of system status.
American Fibertek - MR-940C - Features
- Compatible with NTSC, (RS – 170A & RS –343A), PAL and SECAM
- Diagnostics: Video, DC Power, Digital Frame Sync, OLI
- Available with Enhanced "Afinety" Intelligent Monitoring System
- Digital Video Transmission
- Serial Digital Transmission
Specifications
Specifications
American Fibertek - MR-940C - Specifications
| Brand Name | American Fibertek |
|---|---|
| Manufacturer Part Number | MR-940C |
| Item Description | 4 Ch Digital Video 10 Bit Module Receiver |
| I/0 Level | 1 Vp-p (3 dB) |
| I/0 Impedance | 75 Ohms |
| Bandwidth | 7 MHz |
| Differential Gain | 0.02 |
| Differential Phase | 0.7 |
| SNR (Unified Weighted) | 60 dB |
| Connector | BNC |
| Wavelength | 1310 nm |
| Loss Budget (62/125) | 12 dB |
| Maximum Distance | 2 Km (Limited by Fiber Dispersion) |
| Connector | ST |
| Operating Temp | -40C to +75C |
| Power Supply | 12 VDC (AFI Part# PS-12D) |
| Size | 8-1/8 x 4-1/8 x 1-5/8 |
