American Fibertek MR404C12VDC 4-Channel Fm Video Module Rx, 6Db, Mm

The American Fibertek MR404C-12VDC is a module receiver component of the 404C series which transmits four channels of high-quality, FM video on one multimode optical fiber at 1300 nm. The 404C Series can be used in applications up to 2.5 Km (1.5 miles). Designed to be completely transparent to all camera and monitor manufacturers, the system requires no field adjustments at installation or additional maintenance thereafter. Diagnostic indicators provide a quick visual indication of system status

Features:

• Compatible with NTSC; RS-170A & RS-343A and PAL
• Diagnostics: Video, Power and Optical Presence
• Full Color Transmission
• Real Time Video Transmission
• PFM Video Transmission

Specifications:

• I/0 Level: 1 Vp-p
• I/0 Impedance: 75 Ohms
• Bandwidth: 10 MHz
• Differential Gain: 5%
• Differential Phase: 3 degrees
• SNR: 55 dB
• Connector: BNC
• Wavelength: 1300 nm
• Maximum Transmission Distance: 2.5 Km
• Loss Budget (62.5/125u): 6 dB
• Dynamic Range: 6 dB
• Connector: ST
• Temperature (Operating) -40 degreesC to +75 degreesC, non-condensing
• Power Supply: 12VDC (AFI Part#: PS-12D)
• Size: 8-7/8" x 5-1/2" x 1-7/8"
