American Fibertek MT220C | Two Channel FM Video Module Transmitter

Two Channel FM Video Module Tx - Single Fiber 1300nm 12dB MM.

The MT-220C operates as half of a transmitter pair for the transmission of two simultaneous, real time, baseband NTSC, PAL, RS170, or RS343 video signals. The MT-220C is designed to operate with the MR-220C or RR-220C two channel video receiver over one multimode fiber optic cable. The MT-220C transmitter accepts up to two video inputs. Each video input modulates a separate FM carrier frequency to allow the total of two video signals to be combined onto one fiber. The 220C Series product is designed to operate over an optical loss budget range of 0 to 12 dB when used on 62.5 um multimode fiber. A maximum distance of 5km can be achieved as long as the overall fiber bandwidth maintains a minimum of 150 MHz at 1300 nm. The MT-220C will also operate on 50 um multimode fiber at a reduced loss budget range. This unit is contained in a compact and rugged extruded aluminum housing with internal dc voltage regulation. The detachable terminal block and LED indicators provide for easy installation and monitoring of video and power supply. The MT-220C is designed for mounting as a modular stand alone unit.
