APC CA3KN22GD | Control Relay, Tesys K, 2 No+ 2 Nc, T Or EQ to 690v, 125vdc Standard Coil
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
APC CA3KN22GD | Control Relay, Tesys K, 2 No+ 2 Nc, T Or EQ to 690v...
Description
Description
TeSys K control relay, 4 contacts (2NO/2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides 125V DC coil with integral device available , connection by spring terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh).
Specifications
Specifications
APC - CA3KN22GD - Specifications
| Range | TeSys |
|---|---|
| product name | TeSys CAK |
| Product or component type | Control relay |
| Device short name | CA3K |
| Contactor application | Control circuit |
| Heat dissipation | 3 W |
| Minimum switching voltage | 17 V |
| Minimum switching current | 5 mA |
| Non overlap distance | 0.5 mm |
| Insulation resistance | > 10 MOhm |
| Height | 58 mm |
| Width | 45 mm |
| Depth | 57 mm |
| Net weight | 0.225 kg |
| IP degree of protection | IP2X |
APC - CA3KN22GD - Videos
| APC CA3KN22GD Video | Click to View |
|---|
