Brand: Belden
|
SKU:
B1353A
Belden 1353A 0101000 | Audio Cable, 24 AWG, 1 Pair, Stranded, 1000 Ft.
Regular price
$318.67
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 1353A 0101000 | Audio Cable, 24 AWG, 1 Pair, Stranded, 1000 Ft.
Regular price
$318.67
Unit price
Description
Description
Belden 1353A 0101000 | Audio Cable, 24 AWG, 1 Pair, Stranded, 1000 Ft.
Specifications
Specifications
Belden - 1353A 0101000 - Product Categories
- Electronic Wire and Cable
- Sound and Security Cable
- Audio/Visual Cable
Belden - 1353A 0101000 - Specifications
| Manufacturer Name | Belden |
|---|---|
| Manufacturer Part Number | 1353A 0101000 |
| Item Description | Audio Cable, 24 AWG, 1 Pair, Stranded, 1000 Ft. |
| Amperage | 3.9 A |
| Approval Listings | NEC/UL-CMR, CEC/cUL-CMG, ECA Approved, IEC-11801, TIA/EIA 568-B.2, NEMA WC-63.1 Cat 5, ICEA 661 |
| Attenuation | 26.4 dB/100m |
| Bend Radius | 1.26 in. |
| CSA | FT-4 Vertical Flame Test - Cables in Cable Trays |
| Capacitance | 14.5 pF/ft. |
| Conductor Count | 1 Pair |
| Conductor Material | Bare Copper |
| Conductor Size | 24 AWG |
| Conductor Stranding | 7 Strands per Conductor |
| Conductor Type | Stranded |
| Frequency Rating | 100MHz |
| Impedance | 100 Ohm Fitted |
| Insulation Material | PO-Polyolefin |
| Jacket Color | Black |
| Jacket Material | PVC-Polyvinyl Chloride |
| Jacket Rating | CMR Riser, FT4 |
| Length | 1000 ft. |
| NEC Rating | UL Listed ART 800 Riser |
| Nominal O.D. | 0.13 in. |
| Package Type | Reel |
| Plenum | Riser |
| Product Type | Analog/Digital Audio Cable |
| Pulling Force | 18 Lbs. |
| Resistance | 29.2 Ohm/1000 ft. |
| RoHS Compliant | Yes |
| Screen/Shield | No |
| Shield Type | Unshielded |
| Shielded | UTP |
| Temperature Rating | -20 to 60 Deg C |
| Thickness | 0.022 in. |
| Voltage | 300 V |
