Brand: Belden
|
SKU:
B27331A
Belden 27331A 0105000 | TC VN/PVC, 3 C #16 Stranded BC, PVC-NYL Ins E2, Black PVC Jacket
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 27331A 0105000 | TC VN/PVC, 3 C #16 Stranded BC, PVC-NYL Ins...
Regular price
$1.46
Unit price
Description
Description
Belden 27331A 0105000 | TC VN/PVC, 3 C #16 Stranded BC, PVC-NYL Ins E2, Black PVC Jacket
Specifications
Specifications
Belden - 27331A 0105000 - Applications
- Power And Control Applications Up To 600V
- Class 1 Division 2 Hazardous Locations
- Recommended Cable Gland Belden Btc075A0551Ra
Belden - 27331A 0105000 - Specifications
| No. of Elements | 3 |
|---|---|
| Size | 16 AWG |
| Stranding | 7x24 |
| UL Temperature | 90°C Dry, 90°C Wet |
| Operating Temperature | Wet/Dry: -30°C to 90°C |
| Stationary Min. | 1.256 in (31.90 mm) |
| Installation Min. | 1.57 in |
| Bulk Cable Weight | 56 lbs/1000ft |
| Environmental Suitability | Indoor, Outdoor, Sunlight Resistance, UV Resistance, Burial |
| Flammability / Reaction to Fire | UL1685 UL Loading, IEEE 1202 FT4 |
| Putup Type | Reel |
